Features:
- REDUCED-EMISSION ENGINE TECHNOLOGY
- ADVANCED COMBUSTION TECHNOLOGY
- STIHL 2-MIX-ENGINE
- ANTI-VIBRATION SYSTEM
- COMPENSATOR
- SINGLE-LEVER MASTER CONTROL
- STIHL ERGOSTART (E)
- CHAIN QUICK TENSIONING (B)
- TOOL-FREE FILLER CAPS
Technical Data:
- Displacement - 31.8 cm
- Power output - 1.5/2 kW/bhp
- Suitable Bar length - 35-40 cm
- Suitable Bar length - 14-16 in
- Weight - 4.6 kg 1)
- Weight - 5.28 / 5.38 kg 2)
- Power-to-weight ratio - 3.1 kg/kW
- Sound pressure level - 100 dB(A) 3)
- Sound power level - 112 dB(A) 3)
- Vibration values left/right - 3.5/3 m/s2 4)
- STIHL Oilomatic saw chain pitch/type - 3/8" P PM3
- STIHL Oilomatic saw chain pitch/type - 3/8" P
- Oil pump - Not adjustable
- Tank volume - 0.27 l
- Chain pitch - 3/8" P
- Chain tensioning - Chain Quick Tensioning
- Filter - Long-term filter system / standard filter
- Filter material - Flocked
- Bumper spike - Steel claw
- Cylinder - 4 channel / chrome
- Oil tank volume - 265 cm
- Sprocket - Sprocket profile
- Anti vibration system - AV steel spring
- Filler cap - Tools
- EPA Certified fuel consumption - 0.75 l/h
- CO - 1039 g/kWh
- Handle type - Standard handle
- Exhaust - Standard muffler
- Carburettor - Compensator / Limiter Caps / scavenging / Standard Carburettors
- Speed at maximum power - 10000 rpm
- Additional features - Ematic chain lubrication system
- EPA Certified fuel consumption - 0.198 glh
- Capacity - 1.94 cu-in
- Rollomatic E, cutting length - 30 cm
1)Without fuel, without bar and chain
2)Without fuel, with bar and chain
3)K-factor according to DIR 2006/42/EC = 2.5 dB (A)
4)K-factor according to DIR 2006/42/EC = 2m / s
